How to Fit Window Blinds

Cassette or classic headrail

There are two different types of headrail that you can get from Graham & Brown. The cassette headrail hides the roll of fabric at the top of the blinds, whereas the classic headrail does not. Depending on which headrail you have, you might have to take slightly different final steps - both have been explained at the end of this guide.

Step 1: face fix or top fix brackets?

When you install your brackets, you'll be able to decide whether you want to 'face fix' or 'top fix' them.

Top fixing is when you insert the screw upwards through the bracket and into a surface above - you will need to do this if you are fitting your blinds in a recess. Face fixing is when you insert the screw through the side of the bracket, into a flat, horizontal surface (such as your wall). This is for blinds that are being fitted outside a recess. You could also use this method to fix the brackets to the window.

• Roller Classic face fix - 6.4cm
• Roller Classic top fix – 4.6cm
• Roller Cassette – 8.0cm

• Roman Classic – 4.5cm (face & top fix the same measurement)
• Roman Cassette – 8.0cm

*Top fix means it will fix into a ceiling or top of a recess.
*Face fix means it will fix into a wall or back of a recess.

Cassette sizes and their protrusions differ based on the size of the roller blind.

Roller Cassette:

• 8cm (Small)
• 9.5cm (Medium)
• 11cm (Large)

Cassette Size	Width (cm)	Max Drop (cm)
Small	40cm – 180cm	40cm – 200cm
Medium	180cm – 250cm	200cm – 250cm
Large	250cm – 300cm	250cm – 400cm

Step 2: Mark where your brackets need to be fixed

Use your pencil to make two marks, showing where each bracket will be fixed. You will want there to be one bracket at either end of the blinds, about 2 inches (Approx 5cm), inside the headrail. If you are fitting your blinds inside the recess, make sure you don't make your marks too close to the window. This is because you need to leave enough space for the operating mechanism, and for the blinds to open and close easily.

If you are fitting your blinds outside the recess, make sure to centrally align with the window frame.

Step 3: Fix your brackets to the wall or lintel

To fix your brackets, you'll firstly need to check what material you are drilling into. Ensure to use the correct rawl plugs suitable for steel, plasterboard, wood, brick etc. You need to drill holes where you made your pencil marks. Insert rawl plugs into the holes and then line up your brackets. Use a screwdriver to insert the screws and firmly attach your brackets.

Roman blinds & blinds with a cassette headrail

Attaching your blinds once the brackets are in place is simple. Hook the headrail into the edge of the bracket, then push it forwards and tilt it down until it clicks into place.

Roller blinds with a classic headrail

With these blinds, you'll need to slot the headrail between the two brackets at either end. Do this by pushing one end of the headrail against the 'plunger end' bracket until it gives way and allows you to lift the other end into place.

Dressing roman blinds

In a similar way to curtains, the fabric (particularly of roman blinds) may be creased from transportation. The blind can be steamed to remove any creases and we recommend it is left down for 48 hours. This will allow the fabric to settle into its new surroundings.
